Description

Construction

• Conductor: Bare Copper
• 4 Twisted Pair: 8C
• AWG: 24
• Construction (MM): 1/0.5
• Stranded Dia.(MM): 0.5
• Insulation: PE
• Nom.Thickness (MM): 0.2
• Insulation Dia.( ±0.005): 0.9
• Separator: PE Cross
• Shield/Braid:
• Overlap(%):
• Darin wire:
• Jacket: PVC
  Nom.Thickness (MM): 0.6
• Outer Dia.( ±0.2MM): 0.5

Perfomance

ELECTRICAL CHARACTERISTICS(20℃)
MAX.CONDUCTOR DC RESISTANCE ( /KM) #24:93.8
MIN.INSULATION RESISTANCE ( /KM) PE:100M
DIELECTRIC STRENGTH AC-500V/1 MIN NO BREAKDOWN
D-C RESISTANCE UNBALANCE:MAX 2%
PAIR-TO-GROUND CAPACITANCE UNBALANCE:MAX. 330PF/100M
INPUT IMPEDANCE: 4-100MHz 100+/-15ohm
MEAN CHARATRERISTIC IMPEDANCE@100MHZ: 100+/-5 OHMS
NOMINAL VELOCITY OF PROPAGETION(NVP) 68+/-2%
PROPAGATION DELAY @ 100MHZ ≧537.6 ns/100M
PROPAGATION DELAY SKEW:MAX. ≧45ns/100M
FREQUENCY RANGE MINIMUN REQUIREMENTS(EQUATIONS)
INSERTION LOSS 4-250MHZ IEC61156-6:EQUATION(2).CONSTANT VALUES SEE TABLE 4
RETURN LOSS 4-250MHZ IEC61156-6:SEE TABLE 10
INPUT IMPEDANCE 4-250MHZ IEC61156-6:SEE TABLE 10
NEXT 4-250MHZ IEC61156-6:EQUATION(6),CONSTANT VALUES SEE TABLE 6
PS NEXT 4-250MHZ IEC61156-6:EQUATION(5),CONSTANT VALUES SEE TABLE 6
ELFEXT 4-250MHZ IEC61156-6:EQUATION(7),CONSTANT VALUES SEE TABLE 6
PS ELFEXT 4-250MHZ IEC61156-6:EQUATION(7),CONSTANT VALUES SEE TABLE 6

Color

Insulation
Cores:Pairs
P1:BL& WH/BL; P2:OR & WH/ORJacket; P3:GR & WH/GR; P4:BRN & WH/BRN
Jacket
