FAB-HGT-16G delivers IP67-rated protection and high-density fiber termination with 16 SC ports in a compact, rugged enclosure.
Fibramérica's FAB-HGT-16G is a next-generation fiber termination box tailored to the evolving demands of high-performance NGN and FTTH networks. This unit is engineered to deliver exceptional fiber management in limited spaces, with robust protection and high-capacity connectivity options.
The IP67-rated enclosure is crafted from durable polypropylene (PP), offering superior resistance against water, dust, and environmental stressors. Designed for both wall-mounted and pole-mounted applications, this box performs reliably in harsh outdoor conditions and challenging deployment environments.
Supporting up to 16 SC ports and a splicing capacity of 96 fibers, the FAB-HGT-16GPRE integrates a precise cable management system that protects the fiber’s bend radius above 40 mm, ensuring minimal signal loss and extended network life. It features 16 dedicated access ports for pre-terminated distribution cables and one uncut feeder cable port for flexible network growth.
With its compact dimensions (350 × 245 × 130 mm) and sturdy design, this box maximizes performance without sacrificing space. Whether for residential rollouts, commercial installations, or fiber access networks, it simplifies implementation, reduces labor costs, and guarantees long-term reliability—supported by Fibramérica's quality standards.
IP67 waterproof and dustproof protection
Supports 16 SC adapters and up to 96 fiber splices
16 ports for pre-terminated distribution cables
1 uncut feeder cable port for scalability
Integrated cable and splice management system
Bend radius control above 40 mm
Durable polypropylene (PP) housing
Wall and pole mounting options
Specification | Details |
---|---|
Model | FAB-HGT-16G |
Enclosure Rating | IP67 |
Material | Polypropylene (PP) |
Adapter Ports | 16 SC ports |
Splicing Capacity | 96 fibers |
Bend Radius Protection | >40 mm |
Cable Ports | 16 preconnectorized + 1 feeder port |
Mounting Options | Wall / Pole mount |
Dimensions | 350 × 245 × 130 mm |
FAB-HGT-16G, FTTH box, preconnectorized enclosure, 16 SC ports, outdoor fiber box, IP67 FTTH, fiber distribution box
Description
Fibramérica’s FAB-HGT-16G is a next-generation fiber termination box tailored to the evolving demands of high-performance NGN and FTTH networks. This unit is engineered to deliver exceptional fiber management in limited spaces, with robust protection and high-capacity connectivity options.
The IP67-rated enclosure is crafted from durable polypropylene (PP), offering superior resistance against water, dust, and environmental stressors. Designed for both wall-mounted and pole-mounted applications, this box performs reliably in harsh outdoor conditions and challenging deployment environments.
Supporting up to 16 SC ports and a splicing capacity of 96 fibers, the FAB-HGT-16GPRE integrates a precise cable management system that protects the fiber’s bend radius above 40 mm, ensuring minimal signal loss and extended network life. It features 16 dedicated access ports for pre-terminated distribution cables and one uncut feeder cable port for flexible network growth.
With its compact dimensions (350 × 245 × 130 mm) and sturdy design, this box maximizes performance without sacrificing space. Whether for residential rollouts, commercial installations, or fiber access networks, it simplifies implementation, reduces labor costs, and guarantees long-term reliability—supported by Fibramérica’s quality standards.
Features
IP67 waterproof and dustproof protection
Supports 16 SC adapters and up to 96 fiber splices
16 ports for pre-terminated distribution cables
1 uncut feeder cable port for scalability
Integrated cable and splice management system
Bend radius control above 40 mm
Durable polypropylene (PP) housing
Wall and pole mounting options
Technical Specifications
Specification | Details |
---|---|
Model | FAB-HGT-16G |
Enclosure Rating | IP67 |
Material | Polypropylene (PP) |
Adapter Ports | 16 SC ports |
Splicing Capacity | 96 fibers |
Bend Radius Protection | >40 mm |
Cable Ports | 16 preconnectorized + 1 feeder port |
Mounting Options | Wall / Pole mount |
Dimensions | 350 × 245 × 130 mm |
FAB-HGT-16G, FTTH box, preconnectorized enclosure, 16 SC ports, outdoor fiber box, IP67 FTTH, fiber distribution box
