FAB-OFC-BIM-A6 Inline Closure 96 cores
Fibramérica developed a complete family of horizontal and dome closures to meet the complex needs of today’s fiber optic networks.
Compartilhe:
Description:
FAB-OFC-BIM-A6 Inline Type Fiber Optic Splice Closure (OFC) is mechanical sealing for reusable application
Specification:
| Model | FAB-OFC-BIM-A6 |
| Type | Inline type |
| Number of Inlet/Outlet ports | 6 ports |
| Cable Diameter | 2 ports×16mm, 4 ports×13mm |
| Maximum Capacity | Bunchy: 96 fibers; Ribbon: 144 fiber |
| Capacity per Splice Tray | Bunchy: single layer: 12 fibers; dual layers: 24 fibers; Ribbon: standard: 3pcs; max.: 6pcs |
| Quantity of Splice Tray | 4pcs |
| Body Material | PC |
| Sealing Material | Thermoplastic rubber |
| Assembling method | Aerial, direct buried, pipelined, wall mounting, manhole |
| Dimension | 390(L)×210(W)×120(H)mm |
| Net Weight | 1.9~2.1KG |
| Temperature | -40℃~65℃ |
Description:
FAB-OFC-BIM-A6 Inline Type Fiber Optic Splice Closure (OFC) is mechanical sealing for reusable application
Specification:
| Model | FAB-OFC-BIM-A6 |
| Type | Inline type |
| Number of Inlet/Outlet ports | 6 ports |
| Cable Diameter | 2 ports×16mm, 4 ports×13mm |
| Maximum Capacity | Bunchy: 96 fibers; Ribbon: 144 fiber |
| Capacity per Splice Tray | Bunchy: single layer: 12 fibers; dual layers: 24 fibers; Ribbon: standard: 3pcs; max.: 6pcs |
| Quantity of Splice Tray | 4pcs |
| Body Material | PC |
| Sealing Material | Thermoplastic rubber |
| Assembling method | Aerial, direct buried, pipelined, wall mounting, manhole |
| Dimension | 390(L)×210(W)×120(H)mm |
| Net Weight | 1.9~2.1KG |
| Temperature | -40℃~65℃ |
