High-Density MPO Rack Chassis | Mod. FAB-MPO-RK144
1U high-density MPO chassis with cassette slots for up to 144 fibers in 19″ racks, optimized for centralized management.
- Description
- Features
- Technical Specifications
Description
The FAB-MPO-RK144 is a modular 1U rack-mount chassis designed to accommodate MPO/MTP cassettes or adaptor panels in high-density fiber distribution systems. It is compatible with MDA, IDA, and HAD installations, and fits into standard 19-inch cabinets for centralized trunk cable management.
Engineered from high-grade cold-rolled steel with anti-corrosion coating and electrostatic powder finish, the chassis offers structural integrity, ease of handling, and long service life. It supports up to 144 fiber cores via 12 x LC duplex or 24 x MPO adapters in standard cassettes, while enabling tool-free front access for efficient maintenance.
With a pull-out drawer mechanism and four times the capacity of traditional patch panels, the FAB-MPO-RK144 dramatically reduces cabinet space usage, making it ideal for core network upgrades, structured cabling, and rapid fiber deployment.
This chassis solution by Fibramérica enhances performance and simplifies upgrades in high-density environments such as enterprise data centers and telecom central offices.
Features
Holds up to 144 fiber cores in 1U space
Compatible with MPO/MTP cassettes and panels
Cold-rolled steel with electrostatic finish
Sliding rail drawer for easy access and maintenance
Dimensions: 482.6 × 384 × 44.3 mm (1U)
Compatible with 12F / 24F LC or MPO modules
Four times density of conventional patch panels
Ideal for MDA, IDA, HAD and ODF racks
Operating temperature: -20 to +70 °C
Technical Specifications
| Specification | Details |
|---|---|
| Model | FAB-MPO-RK144 |
| Type | 1U MPO/MTP Rack Chassis |
| Material | Cold-Rolled Steel + Powder Coating |
| Dimensions | 482.6 × 384 × 44.3 mm |
| Fiber Capacity | Up to 144 cores |
| Cassette Support | 12F / 24F MPO or LC Cassette |
| Access Type | Front Sliding Drawer |
| Finish | Degreased + Phosphate + Powder Coated |
| Operating Temperature | -20 to +70 °C |
