Horizontal Fiber Optic Splice Closure (OFC)

Durable ABS horizontal splice closure with up to 96-core capacity and IP-rated sealing | Mod. FAB-OFC-BIM Series

SKU FAB-OFC-BIM-A6S24-4VG / FAB-OFC-BIM-B6S24-4VG / FAB-OFC-BIM-C8S24-4VG / FAB-OFC-BIM-D6S24-4VG / FAB-OFC-BIM-E6S24-4VG / FAB-OFC-BIM-F4S24-2VG Categories , Tags , , ,

Compartilhe:

  • Description
  • Features
  • Technical Specifications
Description

The FAB-OFC-BIM Series Horizontal Fiber Optic Splice Closures are designed to provide reliable and long-term protection for fiber splicing points in FTTx and backbone networks. Constructed with high-quality ABS material, these closures guarantee durability and resistance in aerial, underground, pipeline, or hand-hole installations.

This series supports capacities ranging from 12 up to 96 fiber cores (depending on the model) with compatibility for both single-side 12-core and double-side 24-core splice trays. The horizontal/half design makes them especially suitable for backbone applications where multiple entry and exit points are needed.

Each closure is fully mechanical sealing based, ensuring strong resistance against environmental conditions such as moisture, dust, vibration, and temperature extremes (-40℃ to +65℃). Optional kits for pressure testing valves and earthing devices are also available.

Thanks to their flexibility and robust sealing, the FAB-OFC-BIM Horizontal Closures offer one of the most cost-effective and reliable solutions for fiber optic splicing protection in FTTx deployments.

Features
  • Horizontal/half-type splice closure design

  • Fiber capacity: 12–96 cores (depending on model)

  • High-quality ABS body for durability

  • Fully mechanical sealing for reusability

  • Compatible with single and double splice trays (12/24 cores)

  • Suitable for aerial, underground, pipeline, or hand-hole installation

  • Cable diameter compatibility: 5–20 mm

  • Operating temperature: -40℃ to +65℃

  • Optional pressure testing valve and earthing device kit

  • Easy assembly and maintenance

Technical Specifications
ModelTypeDimensions (mm)Weight (g)PortsCable DiameterCapacityMaterialTemperature
FAB-OFC-BIM-A6S24-4VGHorizontal390×210×1201900–220065–16 mm12–96 coresABS-40℃~65℃
FAB-OFC-BIM-B6S24-4VGHorizontal320×210×852000–250065–20 mm12–96 coresABS-40℃~65℃
FAB-OFC-BIM-C8S24-4VGHorizontal450×220×1102800–330085–20 mm12–96 coresABS-40℃~65℃
FAB-OFC-BIM-D6S24-4VGHorizontal395×195×1302100–260065–20 mm12–96 coresABS-40℃~65℃
FAB-OFC-BIM-E6S24-4VGHorizontal430×180×1251900–230065–20 mm12–96 coresABS-40℃~65℃
FAB-OFC-BIM-F4S24-2VGHorizontal340×150×701500–170045–16 mm12–48 coresABS-40℃~65℃

FAB-OFC-BIM, horizontal splice closure, fiber optic closure, IP-rated splice box, 96-core fiber closure, ABS fiber box, FTTx splice protection
