Description

The TM530A Optical Power Meter by Fibramérica is a professional-grade handheld tool designed to accurately measure optical power in fiber optic networks. It is engineered to support a wide wavelength range from 800 to 1700 nm, covering essential testing frequencies used in FTTH, datacenter, and ISP infrastructures.

Equipped with LED lighting and compatible with FC/SC connectors, this device ensures high precision and operational flexibility in the field. The TM530A offers a linear display with 0.1% resolution and a logarithmic resolution of 0.01 dBm, ensuring clear and reliable readings even in demanding environments.

Compared to conventional meters, the TM530A stands out for its user-calibration capability, wavelength memory retention, real-time battery status, and configurable auto shut-off, all while maintaining low power consumption for extended use.

Its portable, battery-powered design (2 AAA) makes it ideal for technicians conducting fiber optic installation, testing, or troubleshooting in home networks, enterprise backbones, or telecom operator deployments.

Features

• Measures optical power from -70 to +10 dBm

• Supports wavelengths from 850 to 1650 nm

• LED lighting function for visibility in dark environments

• Auto shut-down and battery level display

• Wavelength memory and self-calibration function

• Compact and lightweight (140g) design

• Uses 2 AAA batteries for easy field replacement

• Optional universal FC/SC connector

Technical Specifications

TM530A, optical power meter, fiber optic tester, LED fiber meter, InGaAs sensor, handheld power meter, FC/SC connector, FTTH tester
