FAB-FSP-F8C ODF
Secure and versatile FAB-FSP-F8C 6U ODF cabinet, wall-mounted or self-standing, for organized fiber optic and network equipment.
Compartilhe:
- Description
- Features
- Technical Specifications
Description
The FAB-FSP-F8C ODF Cabinet is a compact, high-quality solution for housing fiber optic distribution frames and networking equipment. With a 6U capacity, it can be wall-mounted or used as a self-standing unit, making it ideal for telecom rooms, small server spaces, and structured cabling installations where space efficiency and organization are essential.
Constructed from durable cold-rolled steel, the FAB-FSP-F8C features a welded frame for maximum strength, along with front and rear tempered glass doors that provide both visibility and protection. The cabinet incorporates removable side panels for easy access during installation or maintenance, with optional locks to enhance security. Cable management is optimized with entry points on both the top and bottom panels, allowing flexible routing of fiber optic and network cables.
For effective cooling, the FAB-FSP-F8C can be equipped with a 120 mm fan (available in 220V or 110V) and includes venting slots to maintain optimal operating temperatures for sensitive equipment. Complying with ANSI/EIA RS-310-D, IEC 60297-2, DIN41491/41494, and ETSI standards, it supports standard 19-inch rack-mount equipment, ensuring broad compatibility.
Designed for professionals who demand performance, durability, and ease of installation, the FAB-FSP-F8C is a premium choice for fiber optic distribution in modern network infrastructures.
Features
6U ODF cabinet, wall-mountable or self-standing
Welded cold-rolled steel frame for durability
Front and rear tempered glass doors
Removable side panels with optional locks
Cable entry on top and bottom panels
120 mm fan option for cooling (220V or 110V)
Complies with ANSI/EIA RS-310-D, IEC60297-2, DIN41491/41494, ETSI standards
Standard 19-inch rack installation method
Compact and sturdy design for space efficiency
Technical Specifications
| Specification | Details |
|---|---|
| Model | FAB-FSP-F8C |
| Material | Cold Rolled Steel |
| Color | Black (Default) / White / Gray |
| Dimensions (H × W × D) | 367 × 600 × 450 mm |
| Installed Capacity | 6U |
| Standard Compliance | ANSI/EIA RS-310-D, IEC60297-2, DIN41491 Part 1, DIN41494 Part 7, ETSI |
| Cooling | 120 mm fan (220V or 110V) option |
| Door Material | Tempered Glass |
| Door Opening Angle | >180° (front and rear) |
| Cable Entry | Top and bottom panels |
FAB-FSP-F8C, 6U ODF cabinet, wall mount fiber cabinet, network rack, 19-inch rack enclosure, telecom cabinet, fiber optic server cabinet
