FAB-OFC-BIM-B6 Inline Closure 96 cores
Compact inline fiber splice closure with mechanical sealing, 96-core capacity | Mod. FAB-OFC-BIM-B6
Compartilhe:
- Description
- Features
- Technical Specifications
Description
The FAB-OFC-BIM-B6 is an inline type fiber optic splice closure built for durability, reusability, and ease of installation in fiber access networks. With a mechanical sealing system, this closure ensures reliable protection and quick re-entry without the need for heat tools or resins.
It supports up to 96 fibers in bunchy configuration or 144 fibers in ribbon, making it suitable for FTTH, enterprise, and mid-sized distribution networks. The closure includes 4 splice trays and features 6 ports with varied cable diameter compatibility—2×13mm, 2×16mm, and 2×20mm—offering greater flexibility for different deployment scenarios.
The enclosure is manufactured with a robust PC body and thermoplastic rubber sealing for optimal resistance to environmental factors. Its compact size and multi-method installation support (aerial, buried, pipelined, wall-mounted, manhole) make it an ideal choice for high-density and space-constrained applications.
Features
Inline type with mechanical sealing
Max capacity: 96 fibers (bunchy), 144 fibers (ribbon)
6 ports: 2×13mm, 2×16mm, 2×20mm
4 splice trays included
PC housing with thermoplastic rubber sealing
Compact design (320×210×85 mm)
Tool-free re-entry and reusable structure
Ideal for aerial, underground, wall, and pipeline use
Technical Specifications
| Specification | Details |
|---|---|
| Model | FAB-OFC-BIM-B6 |
| Type | Inline type |
| Sealing Structure | Mechanical |
| Number of Inlet/Outlet Ports | 6 ports |
| Cable Diameter | 2×13mm, 2×16mm, 2×20mm |
| Max Capacity | Bunchy: 96 fibers; Ribbon: 144 fibers |
| Capacity per Tray | Bunchy: 12/24 fibers; Ribbon: up to 6 pcs |
| Splice Tray Quantity | 4 pcs |
| Body Material | PC |
| Sealing Material | Thermoplastic rubber |
| Installation Methods | Aerial, buried, pipelined, wall, manhole |
| Dimensions | 320×210×85 mm |
| Net Weight | 2.65–2.8 kg |
| Temperature Range | -40℃ to 65℃ |
FAB-OFC-BIM-B6, inline fiber closure, 96 core fiber splice, compact inline joint, FTTH closure, mechanical sealing OFC
