MPO-32 Patch Cord | Mod. FAB-MPO32-PC
MPO-32 patch cord for 100G/400G connectivity in high-density data centers using OM1–OM5 and G.657A fibers.
- Description
- Features
- Technical Specifications
Description
The FAB-MPO32-PC is a 32-fiber MPO patch cord engineered for ultra-high-density fiber deployments in modern data centers and cloud infrastructure. Supporting both single-mode (G.657A1) and multimode (OM1 through OM5) fibers, this patch cord enables high-speed transmission for applications up to 400G Ethernet.
It is available with male or female MPO connectors and includes guide pins when required. The assembly is factory-terminated, 100% tested for insertion loss, return loss, interferometric geometry, and visual inspection, ensuring compliance with TIA/EIA-568-C and IEC 61754-7 standards.
Designed to minimize cabling complexity, the FAB-MPO32-PC simplifies large-scale fiber management, especially in spine-leaf architectures and hyperscale networks. It is available with LSZH, OFNR, or OFNP jackets, tailored to specific environment and safety requirements.
This solution is ideal for structured cabling, migration to parallel optics, and breakout applications, ensuring rapid deployment with excellent optical performance.
Features
MPO-32 high-density connector (male or female)
Supports multimode (OM1–OM5) and single-mode (G.657A1)
Ideal for 100G/400G Ethernet and breakout architectures
Factory polished and interferometer-verified
Insertion loss: ≤0.70 dB (Std), ≤0.35 dB (Elite)
Return loss: ≥60 dB (SM), ≥20 dB (MM)
Jacket options: LSZH, OFNR, OFNP
Custom lengths available for flexible deployment
Durable: ≥500 mating cycles
Fully standards-compliant (TIA/EIA, IEC, GR-1435)
Technical Specifications
| Specification | Details |
|---|---|
| Model | FAB-MPO32-PC |
| Connector Type | MPO-32 (Male/Female) |
| Fiber Type | OM1–OM5, G.657A1 |
| Core Count | 32 fibers |
| Insertion Loss | ≤0.70 dB (Std), ≤0.35 dB (Elite) |
| Return Loss | ≥60 dB (SM), ≥20 dB (MM) |
| Durability | ≥500 matings |
| Jacket Options | LSZH / OFNR / OFNP |
| Operating Temp | -20 to +70 °C |
| Standards | TIA/EIA-568-C, IEC-61754-7, IEC-60793, GR-1435-CORE |
