Main gateway for indoor fiber networks with adaptive GPON/XGPON uplink, Wi-Fi 6 AX3000, 1 × 2.5GE + 3 × GE ports and 4 × RJ11 FXS interfaces. Connects up to 32 compatible secondary gateways, subject to network design.
Main gateway only. Secondary gateways and distribution components are specified separately.
Need a custom spec or OEM branding on this product? Talk to our engineering team.
Every batch, before shipment
Manufacturing
Custom specs and branding
Americas, Europe and Africa
The Fibramérica FTTO Main Gateway is the central device in an indoor fiber network. It receives the optical access connection and distributes connectivity through Wi-Fi and Ethernet. Its downstream GPON interface connects compatible secondary gateways installed in different rooms or work areas.
This arrangement supports FTTO (Fiber to the Office) and FTTR (Fiber to the Room) projects in offices, hotels and other buildings. The main gateway, secondary gateways and optical distribution components are selected together to match the layout and expected demand.
The adaptive GPON/XGPON uplink provides flexibility when specifying the operator connection. Four Ethernet ports, including one 2.5 Gigabit Ethernet port, connect wired devices. Dual-band Wi-Fi 6 serves compatible wireless clients. Four RJ11 FXS ports provide analog telephone connectivity when the corresponding voice service is configured.
Routing and bridge modes, traffic management, access controls and local web administration support network setup and operation. Remote management and voice functions depend on the selected platforms, services and configuration.
For ceiling installation, explore the Fibramérica FTTO Ceiling Gateway with Wi-Fi 6 and Gigabit Ethernet.
For local connectivity in rooms and offices, explore the Fibramérica FTTO Desktop Gateway with Wi-Fi 6 and 2.5GbE. The main gateway, secondary gateways and distribution components are selected together for each project.
For distribution points with four terminal outputs and a cascade connection, explore the Fibramérica FTTO Powered Optical Splitter. The splitter, cabling and terminal power configuration are selected for each installation.
This product covers the main gateway. Secondary gateways, optical splitters, fiber, hybrid cables, connectors and installation are specified separately. Support for up to 32 secondary gateways indicates connection capacity; it does not mean that 32 units are included.
Optical uplink compatibility and provisioning must be validated with the operator. Downstream gateways must be compatible with this system. Power accessories, internet and telephone services, management platforms and any licenses are defined in the project quotation.
| Specification | Details |
|---|---|
| Product role | FTTO main gateway for indoor fiber networks |
| Installation | Desktop |
| Optical uplink | Adaptive GPON/XGPON |
| Optical downlink | 1 × GPON interface (asymmetric) |
| Secondary gateway capacity | Up to 32 compatible secondary gateways; subject to network design |
| Ethernet interfaces | 1 × 2.5 Gigabit Ethernet + 3 × Gigabit Ethernet |
| Wireless | Wi-Fi 6, AX3000; 2.4 GHz and 5 GHz |
| MIMO and antennas | 2 × 2 MIMO; 4 antennas |
| Wireless standards | IEEE 802.11b/g/n/ac/ax |
| Wireless configuration | Multiple SSIDs, automatic rate adjustment, selectable channels and adjustable transmit power |
| Analog telephone interfaces | 4 × RJ11 FXS |
| SIP extensions | Up to 32; subject to voice platform and configuration |
| USB | 1 × USB 3.0 |
| Console | Supported |
| Memory / flash | 1,024 MB / 256 MB |
| Concurrent users | 300 specified; actual capacity depends on workload and network design |
| Power specification | 12 V, 25 W |
| Dimensions | 245 × 179.5 × 43.5 mm |
| Housing | Metal |
| Operating temperature | −10 °C to +50 °C |
| Storage temperature | −20 °C to +70 °C |
| Operating humidity | 5%–95%, non-condensing |
| Operating modes | Routing and bridge |
| IP access | Static IP, DHCP client, PPPoE and WAN subinterfaces |
| Core networking | Static routing, NAT, port mapping, DNS, NTP and DHCP service |
| Traffic management | QoS and bandwidth policies |
| Security | Access controls, IP address allowlists/blocklists, IP/MAC binding, ARP protection and attack-filtering functions |
| VPN and overlay support | IPsec, L2TP and VXLAN |
| Local / remote management | Web interface / TR-069 and MQTT |
| Maintenance | Configuration backup/restore, firmware updates, factory reset, logs and diagnostics |
| Voice signaling | IMS/NGN SIP and H.248 |
| Voice codecs | G.711A, G.711U, G.729, G.723.1 and G.722 |
| DTMF / fax | RFC 2833, SIP INFO and in-band / T.30 transparent transmission and T.38 |
| Call functions | Caller ID, call waiting, hold, transfer and three-way calling; services depend on the voice platform and configuration |
AX3000 is a nominal aggregate wireless rate class. Actual throughput depends on the access service, network design, radio environment and client devices.
The listing covers the main gateway. The number and type of secondary gateways, distribution components and accessories are selected and quoted separately.
They receive the fiber connection from the main gateway through the designed distribution network and provide local connectivity in rooms or work areas. The required Ethernet ports, mounting format and power arrangement depend on the selected secondary model.
The uplink supports adaptive GPON/XGPON. Compatibility with the operator OLT, provisioning and service configuration must be confirmed for the project.
AX3000 describes the nominal aggregate wireless rate class. Internet and device speeds depend on the access service, network design, radio conditions and client equipment.
