10G BIDI SFP+ Transceivers enable full-duplex bi-directional transmission over a single fiber up to 80km.
Need a custom spec or OEM branding on this product? Talk to our engineering team.
Every batch, before shipment
Manufacturing
Custom specs and branding
Americas, Europe and Africa
FIBRAMERICA’s 10G BIDI SFP+ Transceivers provide reliable, high-speed bi-directional data transmission over a single-mode fiber using WDM technology. Designed to meet the IEEE 802.3ae 10GBASE-BX standard, these modules utilize different wavelengths for transmit and receive, enabling full-duplex communication through a single fiber core.
With data rates up to 11.3 Gbps and reach options ranging from 10 to 80 kilometers, these modules are ideal for dense fiber applications in data centers, carrier networks, CPRI/OBSAI links, and enterprise backbones. Each module features a DFB laser for transmission and an integrated photodetector for reception, all packaged in a compact, RoHS-compliant design.
Fully compatible with SFP+ MSA and supporting digital diagnostic functions via SFF-8472, these transceivers are available in temperature grades from commercial (0 ~ 70°C) to industrial (-40 ~ 85°C), ensuring robust operation across varied environments.
Bi-directional 10G transmission on a single fiber
Compliant with IEEE 802.3ae 10GBASE-BX and SFP+ MSA
Data rates up to 11.3 Gbps
Transmission distances: 10, 20, 40, 60, and 80 km
Simplex LC connector interface
Digital Diagnostic Monitoring (DDM)
RoHS compliant
Operating temperature: 0 ~ 70°C or -40 ~ 85°C
| Specification | Details |
|---|---|
| Model | 10G BIDI SFP+ Transceivers |
| Data Rate | 10Gbps (up to 11.3Gbps) |
| Wavelength Options | 1270/1330nm, 1330/1270nm, 1490/1550nm, 1550/1490nm |
| Distance | 10km to 80km |
| Connector | Simplex LC |
| Fiber Type | Single-mode fiber (SMF) |
| Compliance | IEEE 802.3ae, SFP+ MSA, SFF-8472, RoHS |
| Power Supply | +3.3V |
| Operating Temperature | 0 ~ 70°C / -40 ~ 85°C |
10G BIDI SFP+, bi-directional transceiver, 10GBASE-BX, simplex LC transceiver, 1270/1330nm, single fiber SFP+, FIBRAMERICA 10G SFP
Our engineering team can confirm compatibility, custom specs and OEM branding options.
