Advanced XPON ONU with 4GE, VOIP, and dual-band Wi-Fi 6 at 1800 Mbps for modern FTTH networks | Model FAB-H822AX
Need a custom spec or OEM branding on this product? Talk to our engineering team.
Every batch, before shipment
Manufacturing
Custom specs and branding
Americas, Europe and Africa
The FAB-H822AX from Fibramérica is a next-generation XPON ONU tailored for FTTH networks, offering an ideal combination of speed, versatility, and comprehensive connectivity. Supporting both EPON and GPON technologies, it auto-adapts to the network environment without requiring firmware or hardware changes.
This high-performance ONU features 4 Gigabit Ethernet ports, a VOIP port (RJ11, SIP protocol), and dual-band Wi-Fi 6 (2.4 GHz + 5.8 GHz) with a combined wireless speed of up to 1800 Mbps. Equipped with 2T2R external antennas with 5dBi gain, it delivers stable and wide-range wireless coverage, perfect for residential and commercial deployments.
The FAB-H822AX offers advanced Layer 2/3 network functionalities such as VLAN tagging, QoS, NAT, IGMP/MLD snooping, and traffic filtering based on MAC, IP, and URL. It supports IPv4/IPv6 dual stack and allows easy installation and remote management through TR-069, OMCI, and OAM protocols.
With a transmission distance of up to 20 km and operating temperature range from -10°C to +45°C, this ONU is engineered for robust performance across diverse deployment conditions. It also includes a CATV port with configurable activation, making it a flexible Triple Play solution for ISPs.
XPON auto-adaptive (EPON/GPON)
Dual-band Wi-Fi 6 (2.4GHz & 5.8GHz), up to 1800 Mbps
4 x GE LAN ports
1 x VOIP port (RJ11, SIP protocol)
2T2R external antennas with 5dBi gain
1 x CATV port (optional activation)
TR-069, OMCI, and OAM support
VLAN, QoS, NAT, IGMP/MLD snooping
Traffic filtering (MAC/IP/URL)
IPv4/IPv6 support
Transmission distance up to 20 km
Operating temperature: -10°C to +45°C
Power consumption <10W
| Specification | Details |
|---|---|
| Model | FAB-H822AX |
| PON Type | XPON (EPON/GPON auto-adaptive) |
| Wi-Fi | Dual-band Wi-Fi 6 (2.4GHz & 5.8GHz) |
| Wireless Speed | Up to 1800 Mbps |
| LAN Ports | 4 x GE RJ45 |
| VOIP | 1 x RJ11 (SIP) |
| CATV | 1 x RF Output (optional activation) |
| Antennas | 2T2R external, 5dBi gain |
| Routing | Layer 2/3, NAT, firewall |
| Traffic Filtering | MAC, IP, URL |
| Multicast | IGMP/MLD snooping |
| IP Support | IPv4 / IPv6 |
| Remote Management | TR-069, OMCI, OAM |
| Max Distance | 20 km |
| Operating Temp. | -10°C to +45°C |
| Power Consumption | <10W |
FAB-H822AX, XPON ONU, Wi-Fi 6 ONU, 4GE ONU, VOIP ONU, FTTH ONU, Dual Band ONU, GPON EPON ONU, TR-069 ONU, CATV ONU
