The FAB-HGT-16R Fiber Optical Distribution Box from Fibramérica is engineered for high-density FTTx deployments, serving as a secure termination point between feeder and drop cables. Suitable for both indoor and outdoor installations, this versatile unit combines splicing, splitting, and distribution in a durable enclosure designed for reliable performance.
Manufactured from strong ABS or PC+ABS materials, the FAB-HGT-16R is IP65-rated, offering full protection against dust, moisture, and adverse weather conditions. Its robust design ensures operational stability across extreme temperatures, from -40℃ to +85℃, making it an ideal choice for challenging environments.
With a maximum splicing capacity of 48 cores, this distribution box offers high scalability for medium-to-large fiber networks. Precision engineering guarantees low insertion loss (≤0.3 dB) and high return loss (≥50 dB UPC, ≥60 dB APC), ensuring optimal signal quality. The unit also supports over 1,000 insertion/extraction cycles, maintaining long-term reliability.
Perfect for ISPs, telecom operators, and infrastructure providers, the FAB-HGT-16R is built to meet the performance and durability demands of next-generation broadband networks.
Supports up to 48 fiber splices.
ABS or PC+ABS material with UV resistance.
IP65 protection for indoor and outdoor use.
Low insertion loss (≤0.3 dB) and high return loss.
Operating temperature range: -40℃ to +85℃.
Wall-mounted, pole-mounted, or aerial installation.
Long service life with >1000 insertion/extraction cycles.
| Specification | Details |
|---|---|
| Model | FAB-HGT-16R |
| Material | ABS or PC+ABS |
| Dimensions (mm) | 328 × 245 × 89 |
| Weight | 1.8 kg |
| Max Splicing Capacity | 48 cores |
| Protection Level | IP65 |
| Operating Temperature | -40℃ ~ +85℃ |
| Relative Humidity | ≤85% (+30℃) |
| Atmospheric Pressure | 70 kPa ~ 106 kPa |
| Insertion Loss | ≤0.3 dB |
| UPC Return Loss | ≥50 dB |
| APC Return Loss | ≥60 dB |
| Insertion/Extraction Life | >1000 times |
