FAB-HGT-8K-2 Fiber Termination Box

FAB-HGT-8K-2 Fiber Splitter Box enables compact, IP68-protected mounting of fiber splitters for FTTH and FTTB networks.

Need a custom spec or OEM branding on this product? Talk to our engineering team.

Factory Tested

Every batch, before shipment

ISO-9001

Manufacturing

OEM Available

Custom specs and branding

Global Delivery

Americas, Europe and Africa

Fibramérica’s FAB‑HGT‑8K‑2 Fiber Splitter Box is a high-density, multi-purpose enclosure designed for mounting fiber splitters and splicing components in FTTH and FTTB networks. This model offers wall-mounted, pole-mounted, or aerial installation options, adapting to diverse field conditions while maintaining compactness and protection.

Its robust design allows internal integration of passive optical equipment, providing a secure housing that shields fibers from environmental damage. Crafted from PP+GF (polypropylene reinforced with glass fiber), the box ensures structural integrity and long-term durability in outdoor and indoor deployments.

With an IP68 waterproof rating, this model supports harsh environments, offering complete dust resistance and submersion protection. Its internal space supports up to 64 splicing cores, making it a reliable solution for complex distribution needs in limited spaces.

The FAB‑HGT‑8K‑2 is particularly well-suited for telecom operators, ISPs, and infrastructure contractors working on last-mile connections in residential buildings or urban expansion areas. The compact form factor (270×217×95.5 mm) and low weight (1.5 kg) make it easy to handle and install.

  • Multi-installation support: wall, pole, aerial

  • Compact design: 270×217×95.5 mm

  • IP68 waterproof protection

  • Max splicing capacity: 64 cores

  • Durable PP+GF body structure

  • Ideal for FTTH/FTTB deployment

  • Lightweight (1.5 kg), easy to transport and install

  • Integrated passive fiber equipment housing

Specification Details
Model FAB‑HGT‑8K‑2
Installation Wall, Pole, Aerial
Material PP+GF
Dimensions 270×217×95.5 mm
Weight 1.5 kg
IP Rating IP68
Max Splicing Capacity 64 cores
Packing Info G.W. 17.5 kg / 10 pcs / 460×290×570 mm
